KBDfans
Kailh 10 switches switches tester
Regular price
$7.90
-
BOX Royal - Tactile 75g | 3.6mm travel BOX Royal Spec Sheet
-
BOX Navy features the same spring as the BOX Pale Blue, but with a thicker clickbar. Sheet
-
BOX Jade features the same spring as the BOX White, but with a thicker clickbar Sheet
- BOX Heavy Dark Yellow- Liner -70g operating force-same stem as the BOX red Sheet
- BOX BOX Heavy Burnt Orange-Tactile-60g operating force-same stem as the BOX white Sheet
- BOX Heavy Pale Blue-Clicky-60g operating force-same stem as the BOX white Sheet
- BOX Black – Linear 60g | 3.6mm travel Sheet
- BOX Red – Linear 45g | 3.6mm travel Sheet
- BOX Brown – Tactile 50g | 3.6mm travel Sheet
- BOX White – Clicky (linear stem with clickbar) 50g | 3.6mm travel Sheet
Enter your tracking number, tracking order status, also can contact us email：wei@kbdfans.cn
kailh
Mechanical keyboard low profile switches Kailh PCB Socket CPG135001S30
Regular price
$1.60
Key Specifications/Special Features:
Rating voltage: 12V AC/DC (maximum) and 2V AC (minimum)
Rating current: 10mA AC/DC (maximum) and 10μA DC (minimum)
Contact resistance: 200mΩ (maximum)
Insulation resistance: 100mΩ (minimum) (100V DC)
Withstand Voltage: AC100V(50-60Hz)
Motion Force: 3.0kgf max
Operating Life: 100 Cycles (can replace switches 100 times)
Product Application:
Mainly applied on computer keyboards,cash registers equipment and Man-Machine
interface.
Rating current: 10mA AC/DC (maximum) and 10μA DC (minimum)
Contact resistance: 200mΩ (maximum)
Insulation resistance: 100mΩ (minimum) (100V DC)
Withstand Voltage: AC100V(50-60Hz)
Motion Force: 3.0kgf max
Operating Life: 100 Cycles (can replace switches 100 times)
Product Application:
Mainly applied on computer keyboards,cash registers equipment and Man-Machine
interface.
These are sold in packs of 10. Quantity 1 = 10 sockets
The order exceeds 10000 pieces, can contact me, we can give you the wholesale price.
Email：wei@kbdfans.cn
Can't use PCB directly on ordinary PCB. If you are the PCB designer, you need to download the specification.
Enter your tracking number, tracking order status, also can contact us email：wei@kbdfans.cn
KBDfans
Silent Aliaz 4 switches tester
Regular price
$4.00
Specs
- Aliaz 60g 70g 80g 100g switches
- Acrylic base
- ABS OEM profile keycaps
Enter your tracking number, tracking order status, also can contact us email：wei@kbdfans.cn
kailh
Mechanical keyboard switches Kailh PCB Socket CPG151101S11
Regular price
$3.00
Sale price
$1.27
232 in stock
Key Specifications/Special Features:
Rating voltage: 12V AC/DC (maximum) and 2V AC (minimum)
Rating current: 10mA AC/DC (maximum) and 10μA DC (minimum)
Contact resistance: 200mΩ (maximum)
Insulation resistance: 100mΩ (minimum) (100V DC)
Withstand Voltage: AC100V(50-60Hz)
Motion Force: 3.0kgf max
Operating Life: 100 Cycles (can replace switches 100 times)
Product Application:
Mainly applied on computer keyboards,cash registers equipment and Man-Machine
interface.
Rating current: 10mA AC/DC (maximum) and 10μA DC (minimum)
Contact resistance: 200mΩ (maximum)
Insulation resistance: 100mΩ (minimum) (100V DC)
Withstand Voltage: AC100V(50-60Hz)
Motion Force: 3.0kgf max
Operating Life: 100 Cycles (can replace switches 100 times)
Product Application:
Mainly applied on computer keyboards,cash registers equipment and Man-Machine
interface.
These are sold in packs of 10. Quantity 1 = 10 sockets
The order exceeds 10000 pieces, can contact me, we can give you the wholesale price.
Email：wei@kbdfans.cn
Enter your tracking number, tracking order status, also can contact us email：wei@kbdfans.cn
kailh
KAILH SPEED SWITCHES (10 switches)
Regular price
$2.80
Kailh Speed Switches with white bottoms. SMD LED Compatible.
Sold in packs of 10.
- Kailh Gold – Clicky 50g | 1.4mm operating travel
- Kailh Bronze – Clicky 50g (Linear Switch with Clickbar) | 1.1mm operating travel
- Kailh Copper – Tactile 50g | 1.1mm operating travel
- Kailh Silver – Linear 50g | 1.1mm operating travel
Enter your tracking number, tracking order status, also can contact us email：wei@kbdfans.cn
cherry
HIROSE ORANGE SWITCHES (1PCS)
Regular price
$10.00
Sale price
$9.60
42 in stock
This is not a new switch, it needs lubrication.
Enter your tracking number, tracking order status, also can contact us email：wei@kbdfans.cn
cherry
CHERRY RGB SWITCHES (10 switches)
Regular price
$4.00
Enter your tracking number, tracking order status, also can contact us email：wei@kbdfans.cn
KBDfans
KAILH BOX SWITCH TESTER (9 SWITCHES)
Regular price
$6.90
9 Switches in Tester (1 of each)
9 Switches in Tester (1 of each)BOX Black
BOX Red
BOX Brown
BOX White
BOX Pale Blue
BOX Dark Yellow
BOX Burnt Orange
BOX Jade
BOX Navy
Shipping Information
Free shipping through 4PX, or paid shipping with FedEx or DHL
ePacket time is not guaranteed and is uninsured. We are not responsible for any products lost during transit that are shipped through 4PX.
Enter your tracking number, tracking order status, also can contact us email：wei@kbdfans.cn
Gateron
ALIAZ SILENT SWITCHES (TACTILE) （10 switches）
Regular price
$5.50
Minimum Order Quantity is 20
• Tactile switch with mold, housing, and stem redesigned by KBDfans
• Silent switch with a lubricated stem that glides smoother than stock switches
• 4 spring weights to choose 60G/70G/80G/100G
• Choice of either Pcb mount (5 leg) and Plate mount (3 leg) - both with transparent housings
• Support for SMD RGB LEDs, 2 Leg LEDs and 4 Leg RGB LEDs
• Transparent housing, Pink-colored stem
• Has a feeling similar to Mx Clear switches, but smoother and better
• Manufactured by Gateron
Enter your tracking number, tracking order status, also can contact us email：wei@kbdfans.cn
kaih
KAILH PRO SWITCHES (10 PCS)
Regular price
$3.00
- CPG151101D222 Purple.PDF Tactile (Purple)
- CPG151101D221 Red.PDF Linear (Burgundy
- CPG151101D223Green.PDF Clicky (Light Green)
Shipping Information
Free shipping through 4PX, or paid shipping with FedEx or DHL
ePacket time is not guaranteed and is uninsured. We are not responsible for any products lost during transit that are shipped through 4PX.
Enter your tracking number, tracking order status, also can contact us email：wei@kbdfans.cn
![[IN STOCK] R10 TIFFANY BLUE TEALIOS (10 switches)](http://cdn.shopify.com/s/files/1/1473/3902/products/11_7b1ecc03-aa05-476f-a3b6-80733fb31481_{width}x.jpg?v=1505715046)
![[IN STOCK] R10 TIFFANY BLUE TEALIOS (10 switches)](http://cdn.shopify.com/s/files/1/1473/3902/products/22_811d3f75-5392-4b12-8d2a-08b4e52a9235_{width}x.jpg?v=1505715047)
![[IN STOCK] R10 TIFFANY BLUE TEALIOS (10 switches)](http://cdn.shopify.com/s/files/1/1473/3902/products/33_60ae300e-523a-41c8-b6c1-656549b05482_{width}x.jpg?v=1505715049)
![[IN STOCK] R10 TIFFANY BLUE TEALIOS (10 switches)](http://cdn.shopify.com/s/files/1/1473/3902/products/44_{width}x.jpg?v=1505715051)
zeal
[IN STOCK] R10 TIFFANY BLUE TEALIOS (10 switches)
Regular price
$8.50
Sale price
$7.50
44 in stock
- 67g - Transparent, Tiffany Blue Stem, PCB Mount [Linear]
Enter your tracking number, tracking order status, also can contact us email：wei@kbdfans.cn
